QY150V633 Truck Crane

QY150V633 Truck Crane

Features

ZOOMLION ZLJ5663JQZ150V truck crane is a fine-performed and high-reliable product which combines our company many years’ manufacturing experience in mobile cranes with advanced international technologies for meeting the market demands. This high-tech product which perfectly integrates mechanical system, electrical system and hydraulic system into a whole will provide you good control performance, excellent jogging performance, large lifting capacity and super lifting height, so it can be applied in many fields of national economic construction. This product can be widely used in chemical industry, mining establishments, oil field, harbor, building sites, and so on to do lifting and hoisting work. Do not use it in strong electromagnetic fields.

This truck crane, with spacious cab and luxurious equipments, adopts full slewing systems, telescopic boom, electro-hydraulic proportional control system and self-made full-width special purpose chassis with 12×6 drive (3 driving axles and 3 steering axles).

The latest electro-hydraulic operated directional control valve and series-connected plunger variable pumps are all of load-feedback function. Open and close type variable system ensures the actuating mechanism to fulfill its working performance to the utmost. The control type of two levers, which are flexible and stepless speed regulated, can carry out any of the 2 crane movements “Spool up main / auxiliary winch”, “Reel off main / auxiliary winch”, “Telescope boom in / out”, “Derrick”, and “Slew” simultaneously. All that not only provides the crane with stable and reliable simultaneous movements but also greatly improves crane’s working efficiency. The safety devices fitted in hydraulic system, such as relief valve, balance valve, hydraulic lock and brake valve etc., prevents the oil line from overloading and the accidents caused by oil pipe breakage.

The safety devices, such as load moment limiter, and lighting systems equipped in the crane ensure your safety during operation and are convenient for night work.

Parameter

Item			Specification	Remarks
Working performance	Max. rated lifting capacitykg		150000
	Max. lifting torque of basic boomkN.m		5292	Radius: 6m
	Max. lifting torque of Max. length boom kN.m		2264	Radius: 22m
	Max. lifting height of basic boomm		13.5
	Max. lifting height of boomm		60	The specifications do not include deflection of boom and jib. The specification in the brackets includes the length of extension.
	Max. lifting height of jib m		78.4 / (86)
Working speeds	Max. hoist rope speed (Main winch) m/min		110	Drum 5^th layer
	Max. hoist rope speed (Auxiliary winch) m/min		75	Drum 3^rd layer
	Boom derricking time s		78
	Boom extending timemin		12
	Max. slewing speedr/min		1.5
Traveling specifications	Max. traveling speedkm/h		72
	Max. gradeability%		40
	Min. turning radiusm		23
	Min. ground clearancemm		280
	Limit for exhaust pollutants and smoke		Conform to related standards.	Conform to GB3847-2005 GB17691-2005 (National StageⅢ)
	Oil consumption per hundred kilometers L		80
Weights	Self weight in traveling conditionkg		54900
	Complete vehicle kerb masskg		54705
	Axle load (axle 1, 2, 3)kg		8700/8700/8700/
	Axle load (axle 4,5,6)kg		20800（2 axles）/8000
Dimensions	Overall dimensions(L×W×H)mm		14950×3000×3950
	Longitudinal distance between outriggers m		7.04
	Transversal distance between outriggers m		8.5（Fully extended）, 6.5（Half extended）
	Boom lengthm		13~59
	Boom angle°		-1.5～82
	Jib lengthm		11 、18.6
	Offset°		0 、 30
Chassis	Model		ZLJ5663	Code: ZLJ5663V3
	Type		II
	Engine	Model	OM502LA
		Rated powerkW/r/min	390/1800
		Max. torqueN.m/r/min	2400/1080
