QUY50 Crawler Crane
Features
Outstanding lifting capacity: leading the trade and exceeding your imagination!
1. The control system applied to this type of crane is an electronic management system, which adopts CAN bus technology, has intelligent fault diagnosis function and is equipped with intelligent color display.
2. The pendant plate made of high-strength plate, which has taken the place of traditional wire rope, has the advantages of excellent rigidity, light weight, great load-bearing capacity and low wind drag etc.
3. The crane is equipped with a self-assembly/dismantling system. No auxiliary crane is required for loading, unloading, assembly and dismantling.
4. The actuating time of brakes and the opening time of valves fitted in winch mechanisms can be adjusted freely to optimum matching state. The applied advanced PLC controller can make every speed parameter be adjusted within specified range in accordance with the user’s habit, which embodies the ergonomic design of our crane.
5. The slewing mechanism has controllable free swing function which can reduce the impacts on the crane and ensure that superstructure starts/stops slewing more stably. The external slewing ring and slewing reducer with great load-bearing capacity and high precision can ensure stable and precise slewing motion.
6. The traveling mechanism can make the crane have high maneuverability and perform such motions as traveling in straight line, one-side crawler steering, differential steering and turning on the spot as well as traveling with load.
7. The crane has free-fall function.
8. The main pump control system, which has the functions of advanced load feedback and electrically-controlled power adjustment, makes the crane have good jogging performance so as to satisfy the demands in different working conditions required by customers.
Parameter
|
Item |
Value |
Remarks |
|
|
Max. lifting capacity × Radiust ×m |
55×3.7 |
||
|
Deadweight with basic boomt |
48 |
||
|
Main boom lengthm |
13~52 |
||
|
Fixed jib lengthm |
6~15 |
||
|
Max. lifting capacity of fixed jibt |
5 |
||
|
Offset angle of fixed jib° |
10,30 |
||
|
Max. length of main boom with fixed jibm |
43＋15 |
||
|
Max. speed of single rope on drum |
Main winchm/min |
120 |
The 4th rope layer |
|
Auxiliary winchm/min |
120 |
The 4th rope layer |
|
|
Derricking winchm/min |
60 |
The 4th rope layer |
|
|
Slewing speedrpm |
0~3.0 |
||
|
Traveling speedkm/h |
0~1.6 |
||
|
Gradeability% |
40 |
||
|
Ground pressureMPa |
0.066 |
||
|
Overall dimensions (L×W×H)mm |
6800×3300×3020 |
||
|
Engine |
Rated power/ rotational speedkW/rpm |
132/2200 |
|
|
Max. output torque/ rotational speedNm/rpm |
750/1300 |
||
|
Emission standard |
EU Stage Ⅲ |
||
|
Crawler gauge × ground contact length × track shoe widthmm |
2540×4700×760 |
Crawler carrier retracted |
|
|
3540×4700×760 |
Crawler carrier extended |
||
Lifting Capacity Table of Main Boom
|
Boom length(m) |
13 |
16 |
19 |
22 |
25 |
28 |
31 |
34 |
37 |
40 |
43 |
46 |
49 |
52 |
|
Falls |
10 |
10 |
8 |
6 |
5 |
5 |
5 |
3 |
3 |
3 |
3 |
2 |
2 |
2 |
|
Radius(m) |
||||||||||||||
|
3.7 |
55 |
|||||||||||||
|
4 |
49.5 |
47.3 |
||||||||||||
|
4.5 |
41 |
40.1 |
38.5 |
|||||||||||
|
5 |
34.3 |
34.2 |
33.7 |
32 |
||||||||||
|
5.5 |
29.5 |
29.4 |
29.3 |
29.1 |
27.5 |
|||||||||
|
6 |
25.8 |
25.8 |
25.6 |
25.5 |
25.4 |
24.2 |
||||||||
|
7 |
20.6 |
20.6 |
20.4 |
20.4 |
20.3 |
20.2 |
20 |
|||||||
|
8 |
17.1 |
17.5 |
16.8 |
16.8 |
16.8 |
16.6 |
16.6 |
16.4 |
16.2 |
|||||
|
9 |
14.6 |
14.5 |
14.5 |
14.3 |
14.2 |
14.1 |
14.0 |
13.75 |
13.6 |
13.4 |
13.2 |
|||
|
10 |
12.7 |
12.55 |
12.5 |
12.3 |
12.3 |
12.2 |
12.1 |
12 |
11.8 |
11.5 |
11.3 |
11.1 |
11.0 |
10.3 |
|
12 |
10 |
9.8 |
9.8 |
9.6 |
9.5 |
9.58 |
9.45 |
9.2 |
9 |
8.8 |
8.7 |
8.5 |
8.4 |
8.3 |
|
14 |
8.1 |
8.1 |
8 |
7.8 |
7.7 |
7.6 |
7.4 |
7.2 |
7.0 |
6.85 |
6.7 |
6.6 |
6.5 |
|
|
16 |
6.8 |
6.5 |
6.4 |
6.35 |
6.3 |
6.1 |
5.9 |
5.7 |
5.6 |
5.5 |
5.4 |
5.2 |
||
|
18 |
5.7 |
5.5 |
5.35 |
5.3 |
5.1 |
4.9 |
4.7 |
4.6 |
4.4 |
4.3 |
4.2 |
|||
|
20 |
4.9 |
4.6 |
4.6 |
4.5 |
4.3 |
4.2 |
4 |
3.9 |
3.7 |
3.6 |
3.5 |
|||
|
22 |
4.0 |
4.0 |
3.9 |
3.7 |
3.6 |
3.4 |
3.3 |
3.1 |
3 |
2.85 |
||||
|
24 |
3.5 |
3.4 |
3.2 |
3.1 |
2.9 |
2.8 |
2.6 |
2.5 |
2.4 |
|||||
|
26 |
2.9 |
2.8 |
2.6 |
2.45 |
2.3 |
2.15 |
1.9 |
1.9 |
||||||
|
28 |
2.4 |
2.3 |
2.1 |
2 |
1.8 |
1.7 |
1.6 |
|||||||
|
30 |
2.1 |
1.95 |
1.8 |
1.7 |
1.5 |
1.4 |
1.3 |
|||||||
|
32 |
1.68 |
1.5 |
1.4 |
1.25 |
1.2 |
1 |
||||||||
|
34 |
1.3 |
1.2 |
1.1 |
1 |
0.8 |
Note:
1.The lifting capacity listed in the table includes the weight of hook and the weight of wire rope between boom head and hook.
2.When tip boom is used to lift the load, the lifting capacity on tip boom is the same as that on main boom of same length in the same working radius.
