CHASSIS
Chassis Model CYZ51Q
Emission Stage Euro III
Engine Power 265 kw
Engine Displacement 14.256L
Driving Type 6*4
Wheelbase 4595+1310 mm
Max. Running Speed 85 km/h
Min. Turning Radius 8.8 m
Approach/Departure Angle 18.2/10.2°
Tyre Type 295/80R22.5
BOOM SYSTEM
Max. vertical reach 42.8 m
Max. horizontal reach 38.8 m
Reach depth 26.6 m
Unfolding height 10.65 m
Boom control mode Manual、wire and wireless remote control are all available
Boom type RZ
Boom section articulation 90/180/180/240/240
Slewing range 365°
Front Outriggers spread 8500 mm
Rear Outrigger spread 8560 mm
End hose length 3 m
Arm attached pipeline diameter 125 mm
HYDRAULIC SYSTEM
Hydraulic System Type Open loop
System Working Pressure 32 MPa
Main Hydraulic Pump Rexroth
Main Hydraulic Pump Type A11VLO190
Main Hydraulic Pump Displacement 190 ml/r
Main Hydraulic Directional Valve VICKERS
Oil Suction&Return Filter SOFIMA
Multi-Way Valve HAVE
Pressure Relief Valve Lixin
Hydraulic Seals PARKER
Hydraulic Hose MANULI
Hydraulic Oil Tank Capacity 600L
Water Tank Capacity 500 L
Water pump
