XZ500 Horizontal Directional Drill

XCMG Horizontal Drectional Drill XZ500



Model



XZ500

Engine



CUMMINS

Rated power

kW

194

Max.pullback/thrusting

kN

500/500

Spindle torque (max)

N.m

18000

Spindle speed

r/min

0-108

Backreaming diameter

mm

Ø900

Tubing length(single)

m

4.5

Tubing diameter

mm

Ø89

Entry angle

°

10-20

Mud flow rate (max)

L/min

600

Mud pressure (max)

bar

100

Overall weight

kg

18000

Dimension(LxWxH)

mm

9280×2755×3000
