Cutting motor power |
200/110 Kw |
|
Oil pump power |
90 Kw |
|
Cutting hardness |
≤80MPa |
|
Cutting range |
Height：4.46 m |
|
Width：5.67 m |
|
|
Operating weight |
58 t |
|
Dimension(LXWXH) |
10.4X3.2X2.13 m |
|
Max Non-removable size(LXWXH) |
3.57X1.8X1.56 m |
|
Max Non-removable weight |
8577 Kg |
|
Cutting head speed |
46/23 r/min |
|
Star wheel speed |
33 r/min |
|
Load capacity |
4.2 m³/min |
|
First transport aircraft speed |
61 m/min |
|
Working speed |
0～7 m/min |
|
Grade ability |
±18º |
|
Gantry height |
400 mm |
|
Underground water pressure |
3-8 MPa |
|
Fuel Tank capacity |
600 L |
|
Ground Pressure |
0.14 MPa |
|
Undercover depth |
0.2m |
|
Ground clearance |
0.25m |
|
Voltage |
AC1140V |
